Salient features of our molds are: Optimised Preform design of molds to ensure dynamic results in bottle blowing Preform molds with valve gate Hot Runner system Manufactured in modular concept for standard interchangeable mold components for ease of replacement. Variation in Preform wall thickness of ±0.10mm, depending on its length Machining tolerances of the order of 0.005mm (5 microns) A well-balanced cooling channel layout and turbulent water flow for consistency in cooling and efficient heat transfer Application of internationally advanced two-step dual taper locating technology Independent self-locking of each cavity to ensure high concentricity of product
Mold Name |
Jar Preform Mould |
Raw Material |
PET, PP |
Cavity No. |
4, 6, 8, 12, 16, 24, 32, 48, 64, 72, 96, etc. |
Injection Gate |
Hot Runner Valve Gate |
Guarantee Time |
5 Million Shots |
Eject way |
Eject Plate or Robot |
Core&Cavity |
S136 (HRC46-48) |
Mold Base |
P20 |
Delivery Time |
60 Working Days |
Mold Feature |
With Interchangeable Insert and Integral Cooling Channel |
A: Mould Design
20 Cavities Jar Edible Oil Bottle Pet Preform Injection Molds
Good pet preform mould design is the first step,PRC mould has 3 designers with more than 15 years experience.
1:We will analyze the feasibility,shrinkage and molding temperature of plastic products.
2 :We will communicate with customers,including details such as weight,style design,size and appearance,stability and wear resistance of plastic products.
3:Design and mold flow analysis are provided free of charge.
B: Mould Metal Material
Choose different steel according to plastic product material,mould life and customers requirements.
We all buy mould raw material from large metal companies.
We personally test the hardness of the mould steel.
There are strict inspection procedures for the hardness of mould steel,and mould life is 1000000 to 3 million shots.
Product Name | Jar preform mould |
Core &Cavity Steel | 2316#steel, S136 stainless steel or based on customer's requirement. |
Mould base & Standard Component | DME,HASCO,MISUMI,LKM,Self-made with P20, 3CR13, 4CR13 material etc. |
Steel hardness: | HRC30-35 for base material. |
HRC45-48 for core and cavity material. | |
HRC60-62 for special parts material | |
Plastic material | PET, PP, etc. |
Cavity Number | 1*4, 1*6, 1*8, 1*12, 1*16, 1*24, 1*32, 1*48 etc |
Injection System | Pneumatic Valve gate with shut off&free-cut or short tail or long tail etc |
Ejector System | Mould slider + Stripper plate ejection |
Cycle Time | Based on PET preform thickness |
Tooling lead time | 30-60 Days |
Mould life | At least 2.0million Shots |
Quality assurance | CE certificate for European customers |
For over 10 years, APEX has been the go-to source for reliable, affordable PET preform moulds. Our experienced team uses modern technology combined with the highest quality materials to create molds that are durable and cost-effective.We have earned the trust of both local and international customers, thanks to our commitment to customer satisfaction. Our staff is continuously refining and innovating the production process to ensure the best quality results.
Our confidence in the quality of our PET preform moulds is backed by more than a decade of experience, and we guarantee that our products will meet the needs of our customers. If you’re searching for quality preform molds at competitive prices, APEX is the perfect partner.
APEX plastic mould company has accumulated significant experience in the plastic injection moulding industry over the last ten years in China. As a result, we have developed substantial knowledge and expertise that allow our company to offer the customers the highest level of skills, knowledge, and dedication in the preform mould market.
No doubt about it, APEX can manufacture a complete set of PET preform moulds on time and accurately, at the best possible PET preform moulds prices.
Our company has gained extensive skill and expertise in preform mould, allowing clients to trust that they will receive top-class service, efficiency, and commitment.With the capacity to build a full set of PET preform moulds promptly, accurately and cost-effectively no matter how elaborate, APEX is ready to meet any customer needs.
Beyond this, we are also able to design and make each PET preform to customers’ particular specifications, as well as provide printing options on each one.
A good preform project development needs consider molding and blowing system together seriously. By professional analysis software and rich making experience, we could evaluate preform shape and bench rate well to avoid future mistakes. Think in future, and we honored a more thinking will be make finished preforms more competitive in market.
Precision tooling machines ensures each inserts and mold component be in standard, it will be easy for maintenance in future. And with brand spare parts, preform users result will be better for practice.
APEX has a powerful team for research and development, which is capable of manufacturing the pet perform molds with 1 cavity to 96 cavities including the pet preform injection molding system. At the same time we can manufacture pet perform molds especially according to customers' injection molding machines. We also design cold parts, hot runners and other main exchangeable components to fix on the imported perform molds.
1. Features of the perform mold. No cutting of valve gate is employed to reduce the labor cost.
2. Advanced hot runner system assures lower level of AA value.
3. Reasonable- designed cold water channels increase cooling effect and shorten the cycle time.
1. The main components of perform molds are made of S136 material (Sweden ASSAB).
2. The mold base is made of imported P20. plate method avoids corrosion efficaciously and assures long life service of the perform molds.
3. German Vacuum stove is imported for heat treatment of the components, which assures the hardness of components HRC45-HRC48.
Many machine tools are imported from America and Japan, such as Machine center, CNC lathers, EDM and so on. All of these increases processing precision, good interchangeability and low eccentricity ≤0.10mm (perform length≤100).
1. German Hotset heating components.
2. German intelligent temperature controller (PID continuous power controlling).
3. Offering temperature controller and voltage controller according to customers' requirement
Inspection tools include projector, hardness tester, stress tester, eccentric tester, electric balance and other inspection tools. The screw neck is made and inspected strictly by the standard of Coca cola and the screw neck has been up to the standard of Coca cola.
Technologists professional in after-sales line and excellent credit assures stable operation of the machines.
APEX provides not only a mold, but a fine plastic PET preform injection molding solution. It’s like a complete preform molding line contained PET preform molds (Preform type ROPP, ALASKA, PCO1810, PCO1881, BPF, 30/25, 29/25, 26/22, 38mm, 48mm, 50-150mm etc), special PET injection molding machine, other accessories such like dehumidify and dryer, auto loader, water tower, chiller and so on. Besides, we will also provide detail factory plan, gas & water& electric plan and engineer service on customer’s factory for equipment installing, parameter adjusting, and operating & maintenance operation.
